SKID STEERS

SKID STEER TAKEUCHI TL8


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Quantity:

Additional Information

OPERATING PERFORMANCE:
Operating Weight - Canopy
8,455 lb
(3,835ikg)
Operating Weight - Cab
8,631 lb
(3,915ikg)
Tipping Load
6,020 lb
(2,731ikg)
ROC (SAE J818 standard 35% tipping load*)
2,105 lb
(955ikg)
ROC with Optional Counterwewight
2,323 lb
(1,054ikg)
Operating Load at 50% of Tipping Load
3,010 lb
(1,365ikg)
Bucket Breakout Force
6,856 lb
(3,110ikg)
Lift Arm Breakout Force
6,709 lb
(3,100ikg)
Traction Force
9,127 lb
(4,140ikg)
Cycle time
Raise-Full Load - 4.0 Seconds
Lower-No Load - 2.5 Seconds
Dump-Full Load - 2.5 Seconds
Curl-No Load - 2.0 Seconds
ENGINE:
Make / Model - Kubota / V3307-CR-Turbo
Tier Rating - EPA Final Tier 4
Cylinders / Displacement
4/203 cu in (3.3L)
Horsepower
74.3 hp (53.2 kW)
Rated / Max Engine Speed
2,600irpm
Maximum Torque
192 ft-lb @ 1,500 rpm (260 Nm)
Engine Lubrication
11.2 qt (11.8 L)
Cooling System
14.8 qt (14.0 L)
Fuel Tank Capacity
19.8 gal (75.0 L)
Fuel Consumption (65% of full load)
2.69 gal / hr (10.2 L/hr)
Electrical System
12 volts / 60 amps
UNDERCARRIAGE:
Traction Drive Type
Hydrostatic Drive w/ Double Reduction Planetary Final Drive
Parking Brake
Spring Applied, Hydraulically Released Multiple Wet Friction Disc
Track Roller Type
Permanently Sealed Rollers with Metal Face Seals
Track Rollers
5 per side
Track Width
15.7 in (400 mm)
Track Ground Contact Length
54.7 in (1,390 mm)
Ground Pressure
Canopy
4.4 psi (30.2 kPa)
Cab
4.5 psi (30.8 kPa)
Maximum Travel Speed
Low
4.6 mph (7.4 km/hr)
High
6.8 mph (11.0 km/hr)
HYDRAULIC SYSTEM:
Hydraulic Reservoir Capacity
10.3 gal (39.0 L)
Hydraulic System Capacity
15.3 gal (58.0 L)
Auxiliary Hydraulic Flow
18.4 gal / min (69.5 L/min)
System Operating Pressure
3,046 psi (21 MPa)
DIMENSIONS:
Front Clearance Radius without Bucket
4 ft 6.0 in (1,375 mm)
Rear Clearance Radius
5 ft 2.4 in (1,585 mm)
Angle of Departure
30 degrees
Maximum Lift Height to Bucket Pin
9 ft 11.0 in (3,030 mm)
Dump Height Fully Raised
7 ft 9.0 in (2,370 mm)
Maximum Dump Angle Fully Raised
38.5 degrees
Maximum Bucket Rollback at Ground Level
30.0 degrees
Reach Fully Raised
2 ft 4.7 in (730 mm)
Overall Width Without Bucket
5 ft 5.4 in (1,660 mm)
Overall Height
6 ft 11.9 in (2,130 mm)
Overall Length (without bucket)
8 ft 11.8 in (2,740 mm)
Minimum Ground Clearance
12.1 in (310 mm)

* Please call us or submit a quote request for pricing and more information about our skid steer takeuchi tl8 rentals in Albertville, Marshall County, and Northern Alabama.
